S$220.00
| Condition | New — Surplus Stock |
|---|---|
| Manufacturer status | In production |
| Product family | Alfa Laval LKB |
| Product type | Sanitary butterfly valve |
| Nominal size | ISO 38 mm |
| Connections | Welding ends, both sides (W/W) |
| Seal ring | EPDM |
| Weight with welding ends and handle | 1.0 kg |
| Alfa Laval product code | 5212 |
| Max. product pressure | 1000 kPa (10 bar) |
| Min. product pressure | Full vacuum |
| Temperature range | -10 °C to +140 °C (EPDM); max 95 °C while operating the valve |
| Product wetted steel parts | AISI 316L |
| Other steel parts | AISI 304 |
| Bushes for valve disc | PVDF |
| Inside surface finish | Ra <= 0.8 µm |
| Product per PED 97/23/EC | Fluids group 2 |
Alfa Laval LKB butterfly valve, ISO 38 mm, welding ends both sides. AISI 316L, EPDM seal ring, PVDF disc bushes. Rated 10 bar and full vacuum.
Sanitary butterfly valve for stainless steel pipe systems, operated by a handle or an LKLA-T pneumatic actuator. -10 °C to +140 °C on EPDM, though Alfa Laval limits the valve to 95 °C while it is being operated.
1 in stock
