Alfa Laval LKB-F butterfly valve, ISO 76 mm, welding ends both sides. AISI 316L, EPDM seal ring, PVDF disc bushes. Rated 10 bar and full vacuum.
Sanitary butterfly valve for stainless steel pipe systems, operated by a handle or an LKLA-T pneumatic actuator. -10 °C to +140 °C on EPDM, though Alfa Laval limits the valve to 95 °C while it is being operated. The LKB-F carries flanges between the two body halves.
The item master records this one as supplied with an LKLA-T Ø85 NO actuator kit, 6 mm disc connection. Alfa Laval prices the valve and the actuator separately, so check what is physically in the box before it ships.
