S$2,950.00
| Condition | New — Surplus Stock |
|---|---|
| Manufacturer status | In production |
| Product family | Alfa Laval Unique SSV Standard |
| Product type | Pneumatic single seat valve, shut-off |
| Nominal size | ISO 25 mm (1 inch) / DN25 |
| Valve body combination | 200 |
| Number of valve bodies | 1 |
| Number of ports | 2 |
| Connections | Welding ends |
| Actuator function | Normally closed (NC), spring return |
| Actuator type | Maintainable |
| Max. product pressure | 1000 kPa (10 bar) |
| Min. product pressure | Full vacuum |
| Air pressure | 500 to 700 kPa (5 to 7 bar) |
| Air connection | R 1/8 inch (BSP), internal thread |
| Temperature range | -10 °C to +140 °C (EPDM) |
| Product wetted seals | EPDM |
| Product wetted steel parts | 1.4404 (316L) |
| Other steel parts | 1.4301 (304) |
| Internal surface finish | Bright (polished), Ra < 0.8 µm |
| External surface finish | Semi-bright (blasted) |
| Tube outside diameter | 25 mm |
| Tube inside diameter | 21.8 mm |
| Tube wall thickness | 1.2 mm |
| Weight | 3.1 kg |
| Control and indication | Alfa Laval ThinkTop V-series (not included) |
Alfa Laval Unique SSV single seat valve, shut-off, ISO 25 mm (1 inch), valve body combination 200 — one body, two ports, welding ends. Rated 10 bar, −10 °C to +140 °C on EPDM.
Hygienic product line duty in dairy, food and beverage plant. Air-operated at 5 to 7 bar, normally closed (NC), spring return, maintainable actuator.
1 in stock
